Description
DC Regulated Power Supply with Single Output and Backlit LCD Display of Variable 0 – 30V / 0 – 5A DC utilising SMT technology.
A reliable, heavy-duty DC power supply suitable for lab work, research, R&D, and industrial use. Its linear design makes for quiet, stable operation with virtually no ripple and minimal delay during conversion, transformation, and adjustment. Widely used in production line test, electrical maintenance, ageing products, battery charging, laboratories, scientific research and teaching and many other areas.
With a maximum output of up to 30 volts and a current capable of 5 amps, the Metravi RPS-3005 has several other beneficial features: two fully operational modes, back-lit LED display with clear resolution, above-average LCD accuracy (+/- 2.%%), and programmable voltage and current.
Notable Specifications/Features:
- Two operational modes: Constant Voltage Mode and Constant Current Mode
- Built-in High Current Limiting for protection
- Built-in thermo-sensor-activated cooling fan
Metravi RPS-3005 DC Regulated Power Supply
Metravi RPS-3005 DC Regulated Power Supply
Metravi RPS-3005 DC Regulated Power Supply UNBOXING
Demonstration on Metravi RPS-3005 DC Regulated Power Supply
Video embedding powered by Webilop
Additional information
| Model | |
|---|---|
| Brand | |
| Warranty | |
| Colour | |
| Display | |
| No of Channel | Single |
| LED Indication | Indicates the presence of current, Indicates the presence of voltage |
| Input Voltage | 220V / 110V |
| Line Regulation Rate | CC ≤0.05% + 5mA, CV ≤0.02% + 2mV |
| Load Regulation Rate | CC ≤0.05% + 5mA, CV ≤0.02% + 2mV |
| Ripple and Noise | CC ≤2mA, CV ≤0.5mV |
| Accuracy | ±10% |
| SMT Technology | SMT Technology |
| Operational Modes | Constant Current Mode, Constant Voltage Mode |
| Variable Output Current | 0 to 5A |
| Variable Output Voltage | 0 to 30V |
- Utilizes SMT Technology
- Green LED Display
- Voltage and Current displayed together
- Multi-turn variable device to provide high precision voltage setting.
- Auto-tracking on PARALLEL and SERIAL working condition
- Presetting the voltage and current
- DC Output Switch
- Extended output terminals
- Continuous working under full load condition
- Constant Current and Constant Voltage Protection
- Short Circuit protection
- Input : 220 / 110V ±10% 50~60Hz
- Variable Output Voltage : 0 – 30V DC
- Variable Output Current : 0 – 5A
View Catalogue: Metravi-RPS-3005 RPS-6005 RPS-3002-2 RPS-3002-3 RPS-3005-2 RPS-3005-3 DC Regulated Power Supply Combined Catalogue
