Description
10MHz, single trace, analogue oscilloscope
Additional information
| Model | |
|---|---|
| Brand | |
| Warranty | |
| Colour | |
| Display | |
| Deflection Factor | 5mV-5V/div |
| Deflection Factor Accuracy | ±5% |
| Input Voltage | 400Vpk |
| No of Channel | Single |
| Bandwidth | 10MHz |
| Trigger Lock | Trigger Lock |
| Trigger Mode | EXT, INT, LINE, TV |
| Trigger Sweep Mode | AUTO, LOCK, NORM, TV |
| Calibration Signal | 0.5V Square wave of 1kHz |
| CRT Effective Working Area | 8x10div 1div=6mm |
| Trigger Sensitivity | INT:1.5div EXT:0.3V |
| Power Consumption | 20W |
| Certifications |
- Single Channel Single Trace Oscilloscope
- Bandwidth: 10MHz
- Confirms to EN61010-1 (1993) and EN-IEC61326-1(1997)
- Wide measurement
- High sensitivity and trigger lock
- Sweep switch adopts digital code switch and accuracy
- Proper to use in colleges and for engineers and technicians
- Deflection factor is 5mV~5V/div in 1-2-5 Sequence in 10 steps
- Accuracy: ±5%
- Maximum Input Voltage: 400Vpk
- Sweep deflection factor is 0.1us/div-0.1s/div
- Accuracy: ±5%
- Trigger Sensitivity: INT:1.5div EXT:0.3V
- Trigger mode: INT, EXT, LINE, TV
- Trigger Sweep Mode: NORM, AUTO, TV. LOCK
- Calibration Signal: 0.5V Square wave of 1kHz
- CRT Effective working Area: 8x10div 1div=6mm
- Auxiliary Power Supply: 220V AC 50Hz
View Catalogue: Metravi OS-5010A Oscilloscopes Catalogue
