METRAVI DDS-1060 DDS FUNCTION GENERATOR
METRAVI DDS-1060 DDS FUNCTION GENERATOR

DDS-1060 DDS Function Generator

METRAVI DDS-1025 DDS FUNCTION GENERATORS DDS-1025 DDS Function Generator
METRAVI DDS-3005 PC BASED ARBITRARY FUNCTION GENERATOR DDS-3005 PC Based Arbitrary Function Generator & Frequency Counter
0 out of 5
( There are no reviews yet. )

₹76,287.00 including GST @18%

60 MHz DDS Function generator, 125MSa/s sampling rate

Categories: ,
Request a Quote
Add to Wishlist
Compare

Description

60 MHz DDS Function generator, 250MSa/s sampling rate

Additional information

Model

Brand

Warranty

Colour

Display

No of Channel

Dual
Frequency Range

Frequency Resolution

1μHz
Accuracy

within 90 days: ±50ppm, within 1 year: ±100ppm (18°C-28°C)
Sampling Rate

250MSa/s
Waveform Type

Arbitrary, DC, Noise, Pulse, Ramp, Sine, Square
Working Modes

Burst, Continuous, Modulation, Output gating, Sweep
Modulation Type

AM, ASK, FM, FSK, PM, PSK, PWM
Interface

LAN Port (Optional), USB
Vertical Resolution

14 bits
Power Source

Mains Operated
Power Consumption

<50W
Harmonic Distortion

DC – 20kHz, 1Vpp<0.2%
Arbitrary Waveform Length

2 to 1Mpts
  • 60 MHz sinewave out, down to 1μHz resolution for full frequency range.
  • 25 MHz pulse waveform with adjustable rise & fall time and duty cycle.
  • 250MSa/s sample rate and 14-bit vertical rsolution.
  • 6-digit high percision meter that is compatible with TTL level signal
  • Standard dual channels with independent output mode
  • 1M arbitrary wave form memory and 48 waveforms non-volatile storage.
  • Multiple modulation types : AM, FM, PM, ASK, FSK, PSK, PWM.
  • Powerful software available to use in PC.
  • 4.3 inch high-resolution TFT color display
  • Standard Interfaces : USB Host, USB Device, optinal Lan.
  • Dual channels can be applied at the same time or independently : internal/external modulation, internal/external.manual trigger.
  • Support frequency sweep and burst output
  • Ease-of-use multipurpose knob and numeric keypad

Note : Metravi DDS-1025/1060 in not equipped with LAN port.

View Catalogue: Metravi DDS-1060 DDS Function Generator Catalogue
