Description
6000 Counts LCD Display, NCV, T-RMS Multimeter, Measures AC/DC Voltage, AC/DC Current up to 20A, Resistance, Temperature, Frequency, Capacitance, Diode, Transistor Test and Continuity Test Facility.
Additional information
| Model | |
|---|---|
| Brand | |
| Warranty | |
| Colour | |
| Display | |
| T-RMS | |
| Data Hold | |
| Auto Power Off | |
| Auto Ranging | Auto Ranging |
| Relative Measurement | Relative Measurement |
| NCV Detection | |
| Duty Cycle Range | 0.1% to 99.9% |
| Diode & Continuity | |
| Transistor Test | Transistor Test |
| Sampling Time | 2-3 times / sec |
| Overload Indication | Overload Indication |
| Polarity | Automatic |
| Low Battery Indication | |
| Power Source | Battery Operated |
| Battery Type | Alkaline |
| Battery Size | 9V |
| No of Batteries | 1 |
| DC Voltage Range | |
| DC Voltage Accuracy | ±0.5% |
| AC Voltage Range | |
| AC Voltage Accuracy | ±0.8% |
| DC Current Range | |
| DC Current Accuracy | ±1% |
| AC Current Range | |
| AC Current Accuracy | ±1.2% |
| Resistance Range | |
| Resistance Accuracy | ±0.8% |
| Capacitance Range | |
| Capacitance Accuracy | ±4.0% |
| Frequency Range | |
| Frequency Accuracy | ±0.1% |
| Temperature Range | |
| Temperature Accuracy | |
| DC Voltage Resolution | 0.1mV to 1V |
| AC Voltage Resolution | 0.1mV to 1V |
| DC Current Resolution | 0.1μA to 10mA |
| AC Current Resolution | 0.1μA to 0.1A |
| Resistance Resolution | 0.1Ω to 0.01MΩ |
| Capacitance Resolution | 1pF to 10μF |
| Frequency Resolution | 0.001Hz to 0.001MHz |
| Temperature Resolution | 1ËšC |
| Certifications |
- T-RMS
- Data Hold to freeze displayed data
- Auto power Off
- Auto-ranging
- Relative Measurement facility
- Non Contact Voltage Detector
- Display: 3-5/6 Digits 6000 counts LCD
- DC Voltage: 0 – 600mV / 6 / 60 / 600 / 1000V
- Accuracy: ±0.5%
- AC Voltage T-RMS: 0 – 600mV / 6 / 60 / 600 / 1000V
- Accuracy: ±0.8%
- DC Current: 0 –Â 600u / 6000u / 60m / 600m / 6 / 20A
- Accuracy: ±1.0%
- AC Current T-RMS: 0 –Â 600u / 6000u / 60m / 600m / 6 / 20A
- Accuracy: ±1.2%
- Resistance: 0 – 600 / 6k / 60k / 600k / 6M / 60M.Ohms
- Accuracy: ±0.8%
- Capacitance: 0 – 6n / 60n / 600n / 6u / 60u / 600u / 6m / 60m F
- Accuracy: ±4.0%
- Frequency: 0 – 9.999Hz ~ 9.999MHz
- Accuracy: ±0.1%
- Duty Cycle: 0.1% to 99.9%
- Temperature: -40 to 1000 ËšC
- Accuracy: ±1.0%
- Duty Cycle, Transistor, Diode and Continuity Test
- Confirms to CE, CAT-II 1000V
View Catalogue: Metravi 19 Super Digital TRMS Multimeter Catalogue
Dr Devojyoti Bag –
It’s a good product. Only drawback is
Its 2nf and 20nf range need relative
mode to overcome errors. Otherwise
it’s useful in scientific studies.
Venkatesan Ganesan (verified owner) –
Good model with low price
