PM-05 Multifunction Differential Pressure Manometer
₹6,413.00 including GST @18%
Differential Pressure Manometer measures negative, positive and differential pressure. Option for 11 measurement units: bar, ozin², psi, mbar, mmHg, cmH2O, ftH2O, kgcm² and kPa.
- Description
- Additional information
- SPECIFICATIONS
- CATALOGUE
- Reviews (0)
Description
The Metravi PM-05 Manometer measures negative, positive and differential pressure.
Option for 11 measurement units: bar, ozin², psi, mbar, mmHg, cmH2O, ftH2O, kgcm² and kPa.
The battery-powered instrument is equipped with a TPU sheath with a simple hose connection device.
Simple and easy to use, with a clear display, it is an ideal instrument for the HVAC and Automobile Repairing industries. It is suitable for detecting waste gas pressure, engine intake manifold vacuum negative pressure, ventilation duct system pressure and also is ideal for line pressure stress tests during troubleshooting systems.
Additional information
| Brand | |
|---|---|
| Colour | |
| Model | |
| Warranty | |
| Pressure Range | ±30psi / 206.8 kPa |
| Maximum Pressure | 206.8 kPa |
| Response Time | 0.5 secs (25°C ±2°C) |
| Accuracy | ±1% FS |
| Measurement Units | Built-in Option for 11 Different Measurement Units |
| Repeatability | ±0.25% FS |
| Linearity/Hysteresis | ±0.1% FS (Linear Hysteresis Phenomenon) |
| Low Battery Indication | |
| Over Range Indication | |
| Mounting Type | TPU Sheath for Harsh/Rugged Environments |
| Power Source | — |
| Interface | — |
| Data Storage | 32 Data Storage |
| Zero Setting Function | Available |
| Auto Power Off | |
| Overload Indication | Over Load Indication Display and Warning Note About Meter Damage if Over-Pressured |
- ±30psi / 206.8 kPa Differential Pressure Sensor
- Built-in option for 11 different measurement units
- ZERO setting function
- TPU sheath for protection when using in harsh and rugged environments
- 32 Data Storage
- Auto Power-off (manual option available)
- Accuracy: ±1% FS
- Linear Hysteresis Phenomenon: ±0.1% FS
- Max. Pressure Limit: 206.8kPa(*)
- Repeatability: ±0.25% FS
- Reaction Time: 0.5 secs (25°C ±2°C)
- Overload Alert: “HI” display(*)
- *IMPORTANT NOTE! Excess or over-limit pressure will damage the meter
View Catalogue: Metravi PM-05 Multifunction Manometer Catalogue Web
